หนึ่งในผู้นำด้านการวัดอย่าง Endress+Hauser ได้ค้นพบโซลูชันที่ช่วยเพิ่มประสิทธิภาพในกระบวนการผลิตอย่างเครื่องมือวัดแรงดัน เครื่องมือวัด ซึ่งสามารถปรับสเกลให้มีความเหมาะสมกับปริมาณการผลิตครอบคลุมการใช้งานในอุตสาหกรรมอาหารและเครื่องดื่ม รวมไปถึงยา ที่ต้องการควบคุมความสะอาดมากเป็นพิเศษ นอกจากนี้ ยังได้รับการออกแบบตามหลักสุขอนามัย อีกทั้งยังใช้งานง่าย สามารถควบคุมการใช้งานผ่านสมาร์ทโฟนและแท็บเล็ตได้อีกด้วย
The new compact product line from Endress+Hauser enables higher productivity, ease of use and offers optimal production scalability. The product line is specifically designed for use in the life sciences and food and beverage industries. The product line covers many hygienic applications, consisting of three measuring principles for measuring pressure, continuous levels, and point levels. The new products offer optimal solutions for small vessels and a standardized and user-friendly design.
Fully focused on industry requirements
The customers’ needs completely drove the development of the new product line. Thanks to the compact sensor design, the small process connections and the outstanding performance, the measuring devices are flexible in scale. The sensors can be used in small vessels and pipes and in bigger process tanks. The products’ 360-degree hygienic design and IP69 ingress protection class enable efficient cleaning. The fully welded stainless-steel devices can also remain in place during cleaning and sterilization processes of plants or tanks. This saves time, simplifies cleaning procedures and helps to avoid contamination. Thanks to a touch display, settings can be made intuitively and within minutes directly on the device. As the display is gap-free there is no risk of contamination.
Multiple technologies to solve a wide range of applications
Whether the pressure of your process pipe needs to be measured when cold, medium-like milk is transferred, the level of base ingredients must be monitored continuously or an overfill protection for process tanks is needed, the compact line offers the right measuring device to solve those tasks.
In pressure measurement technology, the new Cerabar PMP43 impresses with a wide range of sensor variants with fully welded, hygienic process connections, which are used in the food and beverage industry and the life sciences sector.
With the Liquiphant FTL43, point levels in almost all pumpable liquids can be detected using the proven vibronic technology. A significant advantage is the wide range of applications that do not require adaptation to different media.
Endress+Hauser also presents the new Micropilot FMR43 free space radar sensor for continuous, contactless level measurement. Thanks to its exceptional performance, the measuring device ensures reliable measurement even under rapidly changing or turbulent process conditions. The hygienic industry’s requirement for even smaller process tanks was also considered during the development of the new devices.
In addition to the proven 80 GHz technology, a one-half-inch process connection can be realized thanks to a 180 GHz frequency option, which allows use in the smallest process tanks. The variety of the mentioned technologies benefit various applications and help to drive the standardization of measurement solutions at the same time.
Maximized product and process safety
All three technologies maintain required industry certificates, such as EHEDG, 3-A, EG 1935 or ASME BPE, to comply with industry requirements. Material conformity and traceability are given through declarations and certificates (e.g. EC1935/2004, FDA and cGMP). Furthermore, the product line was developed with a tamper-proof design, which means protection against manipulation. Process-critical parameters can be safely locked, and configuration integrity maintained using the safety mode wizard. A proven user role concept supports operators by assigning distinct roles and permissions to control who accesses what, enhancing security and accountability. Heartbeat Technology is a powerful tool for ensuring batch-centric operations. Within minutes, it offers a traceable and documented on-demand verification according to ISO9001. Also, every batch meets the highest standards of quality and safety.
Improved plant performance thanks to increased transparency
The new compact product line can increase production process productivity. The Heartbeat Technology functionalities developed by Endress+Hauser, combined with reliable and comprehensive diagnostics, process and device monitoring, can detect process anomalies such as foam formation or build-up at an early stage. This reduces the risk of plant shutdowns. Additionally, qualitative device health verifications are performed in less than three minutes without disassembly or process interruptions.
Using the traceable in-situ verification function of Heartbeat Technology, calibration intervals can be optimised. An example is the Micropilot FMR43 and the Radar Accuracy Index (RAI). The RAI evaluates the reference measurement accuracy during traceable verification according to ISO 9001 to analyse a possible measurement drift compared to the validated state via factory calibration. In this way, plant operators always have transparency regarding the accuracy of the measuring devices.
Easy to operate due to digital assistance
The new measuring instruments of the compact product line simplify measuring tasks in every respect. The entire product line uses an identical user interface across all technologies. This makes installing, commissioning and operating the devices easier and more intuitive than ever. Numerous digital wizards guide users through commissioning and parameterization. This saves valuable time and helps to prevent human errors. All analyses, controls, maintenance, or function checks can be conveniently performed remotely via smartphone or tablet using Bluetooth® Technology and the SmartBlue app from Endress+Hauser. In addition, the devices can also be integrated into engineering systems or software tools for parameterization and control via digital communication with an IO-Link or HART connection, for example.
Your benefits
Outstanding simplicity
Easy setup and operation thanks to guided wizards for commissioning, verification and periodic proof tests
Harmonized user interface across multiple measurement technologies drives standardization and saves valuable time for training
Intuitive and remote operation via Bluetooth® Technology and the SmartBlue App – no need to access the measuring point physically
Increased productivity
High scalability and flexible use in small and big vessels thanks to compact sensor design, small process connections, and outstanding performance
Improved plant performance thanks to increased transparency with the help of Heartbeat Technology
Easy device integration into asset management systems thanks to digital communication (via HART or IO-Link)
<
Product + process safety
Documented compliance through certified hygienic design (3-A, EHEDG, ASME BPE) and proven material conformity and traceability through declarations and certificates (e.g. EC1935/2004, FDA and cGMP)
Reliable measurement due to process monitoring and permanent device diagnostics with Heartbeat Technology
Improved process and product safety through tamper-proof design – a checksum algorithm (CRC) ensures that safety-relevant process parameters remain unchanged
Compact design, full performance. Endress+Hauser boasts a new product line for continuous level, point level and pressure measurement in hygienic applications.
For further information, please visit https://www.th.endress.com/
